SUCTION SIDE MANIFOLD FOR 2 PUMPS STAINLESS STEEL AISI304

Descrizione

Material: Inox 304L (1.4306) on request may be provided cer.ficates of raw material
Threads: In accordance with UNI EN ISO 228-1 cilindrical
Superficial treatment: electrochemical polishing DIN 8590
Weld: TIG gas tungsten arc welding GTAW UNI EN 1418 Welders cer.fied by Italian Ins.tute of welding IIS member IIW EWF in accordance with EN ISO 9606-1:2013
Tube thickness: 3mm
Superficial treatment: electrochemical polishing DIN 8590
Manifold reating: PN16

  CODICE A
lenght
B
Main
pipe
C
Outlets
D
Outlets
E
distance
between
the pumps
F
G
Weight
in Kg
6500X 500 mm 1″1/2 1″M 1″F 300 mm 370 mm 1/4″F 1,92
6503X 500 mm 2″ 1″M 1″F 300 mm 370 mm 1/4″F 2,41
6501X 500 mm 2″ 1″1/4M 1″F 300 mm 370 mm 1/4″F 2,45
6510X 700 mm 2″ 1″1/4M 1″F 360 mm 370 mm 1/4″F 3,00
6505X 500 mm 2″ 1″1/2M 1″F 300 mm 370 mm 1/4″F 2,50
6511X 700 mm 2″ 1″1/2M 1″F 360 mm 390 mm 1/4″F 3,34
6502X 500 mm 2″1/2 1″1/4M 1″F 300 mm 370 mm 1/4″F 3,00
6513X 700 mm 2″1/2 1″1/4M 1″F 360 mm 390 mm 1/4″F 3,50
6506X 500 mm 2″1/2 1″1/2M 1″F 300 mm 370 mm 1/4″F 3,10
6512X 700 mm 2″1/2 1″1/2M 1″F 360 mm 390 mm 1/4″F 6,60
6504X 700 mm 3″ 2″M 1″F 360 mm 390 mm 1/4″F 5,80
6514X 700 mm DN100* 3″M 1″F 360 mm 390 mm 1/4″F 8,00
* flanged
